BOCHUANG SPACETIME (BCSK-PBTX06) – The Ultimate Full-Spectrum Suppression Tool: 900M-5.8G, Six-Band High-Gain IntegratedAluminum Alloy Flat Roof

Line Component

Product Details

AtLow-Altitude Defense and Electronic WarfareThe coverage breadth of domains and frequency bands directly determines system effectiveness. Bochuang Space-Time'sBCSK-PBTX06 Six-BandTablet Targeting Group

Align antenna, is a rare ultra-wideband integrated solution on the market. It integrates within a compact aluminum alloy planar form factor900MHz、1.2GHz、1.5GHz、

2.4GHz, 5.2GHz, and 5.8GHzSix core RF channels. This antenna is purpose-built to counter complex and evolving drone threats, ranging from low-frequency long-range remote controls

Link (900M/1.2G) to core satellite navigation signals (1.5G), then to high-frequency WiFi control and HD video transmission (2.4G/5.2G/5.8G), achieving true

"Full-band, zero-blind-spot" coverage. Thanks to an optimized microstrip array design and high-quality aluminum alloy substrate, this component ensures high isolation between frequency bands while delivering complete

Frequency Band1 2dBistable high-gain output with a VSWR as low as1.2with extremely high energy transmission efficiency. It is designed to build the next generation of portable drone countermeasure systems.

Core RF front-end for vehicles, onboard interference systems, and fixed defense sites.

Core Advantages & Technical Highlights:

• Six-band integration, ultimate consolidation:


  Compared to traditionalTri-band antennaorQuad-band antenna, BCSK-PBTX06 has been additionally added900 MHz(partial industrial UAVs and legacy radio control links) and1.2GHz

  (specific video transmission and civil frequency bands) and5.2GHzSupport for (some dual-band WiFi drones). A single antenna can replace multiple independent antennas, greatly simplifying the feed

  Linear layout reduces device weight, making it ideal for handheld devices.

• Full-bandwidth 1 2dBi high gain and low VSWR:


  Typically, wideband antennas struggle to maintain performance across all frequency bands. However, this product achieves precise impedance matching design, ensuring consistent performance across all operating bands.1 2dBiof

  High gain and1.2exceptionally low VSWR, enabling greater effective range, reduced signal reflection loss, and better protection for the power amplifier module.

• Industrial-grade Aluminum Alloy Heat Sink Substrate:


  Constructed from high-strength aluminum alloy for both the radiator and ground plane, this design offers exceptional mechanical strength and superior thermal conductivity. During high-power continuous interference operation, it rapidly dissipates heat.

  Dissipate heat to prevent thermal drift in antenna performance and ensure stable long-term operation.

• Flexible, customizable services:


  Supports customization of frequency bands, gain levels, connector types (e.g., N-type, F, TNC), and cable lengths to perfectly fit various non-standard requirements.

  Standard system integration.

Technical Specifications:

Application Areas:

• Air Defense for Critical Areas and Low-Altitude Defense:Drone intrusion defense for sensitive areas such as airports, prisons, military bases, and nuclear power plants.

• Major Event Security:Radio security assurance and control of unauthorized drones for sports events and large-scale conferences.

• Individual Operations and Specialized Missions:cooperatePortable JammerExecute close-range rapid response missions.

• Electromagnetic Environment Testing:For transmit and receive testing of multi-band radio signals.

Frequently Asked Questions (FAQ):

Q1: What advantages does this six-band antenna offer over a standard three-band model?

A: The biggest advantage isBand IntegrityStandard tri-band antennas typically cover only 1.5G/2.4G/5.8G, often missing specialized drones operating on the 900M or 1.2G bands.

(such as certain FPV drones or modified models). BCSK-PBTX06Tablet Directional Array AntennaAchieved full coverage from 900M to 5.8G, ensuring reliability when facing unknown or specially modified scenarios.

Still valid for the target.

Q2: What does a VSWR of 1.2 for the antenna indicate?

A: Voltage Standing Wave Ratio (VSWR) is a key metric for measuring the match between an antenna and its feed line. 1.2 is an excellent value (ideal: 1.0), indicating that the antenna effectively handles RF signals.

The system achieves extremely high energy absorption efficiency with minimal energy reflected back to the amplifier. This extends interference range while effectively protecting expensive amplifier modules from burnout.

Q3: Can the interface and cable length be customized?

A: Absolutely. We support deep customization, including swapping toN-type connector, TNC connectors, or other high-power interfaces, or custom-tailored to your equipment's installation space.

Low-loss RF cables for short lengths.
