Bochuang Space-Time BSKS-BB08 Shoulder-Mounted Drone Countermeasure System, 8 Band, 0W High Power, Effective Range 500-1500 Meters, Portable Single-Operator Anti-Drone Jammer
This portable drone countermeasure system features a rugged metal enclosure and four high-gain fiberglass omnidirectional antennas. It covers mainstream drone communication bands: 400-470 MHz, 840-930 MHz, 1160-1280 MHz, 1550-1620 MHz, 2380-2500 MHz, 5150-5300 MHz, and 5720-5880 MHz. Each band delivers up to 30W of output power, with an effective range of 500 to 1500 meters. Powered by an internal DC 28V/20000mAh high-capacity battery, it supports extended field operations. With dimensions of 480×360×140 mm and a weight of 18.5kg, the unit is easy to carry on foot or mount in vehicles. By precisely jamming critical links such as remote control, video transmission, and navigation, it achieves non-kinetic interception—making it a reliable choice for low-altitude security.
In Stock (500units
Product Overview
This high-performanceBackpack-styleDrone Countermeasure System EquipmentEngineered for single-soldier mobility and rapid deployment. The BCSK-BB08 from Bochuang Space-Time comes in a military-grade ruggedized metal enclosure.
The unit weighs no more than 18.5kg and features an ergonomic harness design, enabling operators to easily navigate hills, muddy roads, and steep staircases, significantly enhancing mobility.
Combat efficiency in complex terrain. Equipped with a built-in DC28V/20000mAh high-capacity battery pack, the device supports extended independent field operations without requiring external power to establish temporary setups.
Low-altitude security barrier. Equipped with 8 independent channels.Jamming Module, capable of precisely jamming the control links, video transmission signals, and satellite navigation systems of mainstream drones; it is a special
Ideal equipment for SWAT, counter-terrorism units, border patrol, and large-scale event security.
Key Features
Seamless full-band coverage: Precisely covers 8 key frequency bands within the 400-5880 MHz range, including common 433MHz, 900MHz, 1.2GHz, and 1.5GHz.
2.4GHz and 5.8GHz, effectively handling consumer and industrial drones.
High-power precision suppression: Each frequency band is equipped with an independent 30WPower Amplifier ModuleEnsure rapid drone neutralization within the effective range of 500–1500 meters.
Control signal and video transmission link.
High-Gain Omnidirectional Antenna: Top configuration with four sets of 360°Fiberglass Omni-directional AntennaDelivers seamless, 360-degree signal coverage without frequent device reorientation, significantly reducing the burden on individual operators.
Difficulty.
High-mobility design: Compact overall dimensions (480×360×140 mm) and weight of only 18.5kg, balancing high power output with single-operator portability for rapid deployment.
For military deployment and mobile patrol control.
Independent battery powerBuilt-in 20000mAh high-capacity battery eliminates reliance on external power, ensuring operation in remote areas, on vehicle roofs, or at temporary checkpoints where no power is available.
Continue executing countermeasures.
Technical Specifications Table
Parameter Item | Specification Value |
|---|---|
Model | BCSK-BB08 |
Countermeasure frequency band | 400-470 MHz 840-930 MHz 1160-1280 MHz 1550-1620 MHz 2380-2500 MHz 5150-5300 MHz 5720-5880 MHz |
Output Power | 30W / Band |
Effective Countermeasure Range | 500 - 1500 meters (varies by drone model and signal strength in different usage scenarios) |
Antenna Type | 360° FiberglassOmnidirectional Antenna |
Power Supply | DC28V / 20000mAh Built-in Battery |
Overall Dimensions | 480 × 360 × 140 mm |
Total Weight | 18.5 kg |
Frequently Asked Questions (FAQ)
Q1: What is the effective range of this backpack UAV jamming system in actual combat?
A: The effective countermeasure range of this device is 500 to 1500 meters. Actual range may vary based on the local electromagnetic environment, terrain obstructions, and target drone signal strength.
Open area, 30WHigh-Power ModuleTypically achieves stable suppression over 1 km.
Q2: How long does the device's battery last on a single charge?
The built-in 20000mAh battery typically supports 1.5 to 2 hours of continuous operation at full load with all 8 frequency bands active. If you only need to operate on specific bands intermittently,
Intermittent countermeasures will extend the battery life accordingly. A spare unit is recommended.BatteryTo handle long-running tasks.
Q3: Will this device interfere with nearby civilian communications, such as mobile phones or Wi-Fi?
A: This device is designed to jam frequencies dedicated to drone remote control, video transmission, and navigation. Although some of these bands (such as 2.4 GHz/5.8 GHz) overlap with civilian Wi-Fi,
However, since the device uses directional or omnidirectional antennas to focus on low-altitude targets, its communication interference range in the horizontal ground direction is limited. When used in densely populated areas, it is recommended to assess the site conditions...
Enable specific frequency bands based on the situation.
Q4: Is the weight of 18.5kg too heavy for a single soldier to carry?
A: 18.5kg balances high power (8 band × 3W) with high mobility. It features a professional tactical backpack system that effectively distributes weight across the shoulders.
Back and waist carry, designed for trained military and law enforcement personnel for extended use. For scenarios requiring a lighter setup, consider the handheld model from Bochuang Space-Time.Drone Countermeasure Equipmentor
Lightweight backpack model.
